The new regulator is for panel mounting and can be used in conjunction with compressed air. It is distinguished by having a high flow and low hysteresis.
Manufactured in a die-cast aluminum housing, available with G1/8 and G1/4 connections. The regulator has integrated manometers directly in the adjustment knob. The 24.5 mm display guarantees easy and precise reading of the regulated pressure value. The system is balanced and uses a rolling diaphragm with low hysteresis, which gives the regulator high precision, stability and repeatability. The combination of these properties provides high flow with low pressure drop. As standard, the regulator is vented for excess pressure.

• Diaphragm pressure regulator

• Aluminum body

• High flow rate with low pressure drop

• Available with G1/8" and G1/4" connections

• Low hysteresis

• 4 pressure adjustment ranges available up to
12 bar

• Equipped with ring nut for panel mounting

• Atex II 2GD approved

• Ø 24.5 manometer integrated on the button

• Manometer with 4 mounting positions in
relation to Inlet (0°-90°-180°-270°)

• Class 4 Manometer (±4% FS)
